Zerothermo vacuum glass is a fully tempered vacuum insulated glass with thinner and lighter structure, it is defined the standards for safety, energy conservation and comfort. As one of the environmentally friendly and energy-saving materials, vacuum glass was widely used for doors, windows, curtain walls, and skylights for commercial and residential buildings, public facilities, green buildings as well as landmark structures.
| Parameter | Specification Details |
|---|---|
| Weight | about 25 kg/㎡ |
| Structure | Hollow |
| Brand Name | Zerothermo |
| Min. Size | 300*300mm |
| Max. Size | 2000*3000mm |
| Service Life | ≥ 50 years |
| Project Solution Capability | graphic design |
| After-sale Service | Online technical support |
| Function | Decorative Glass, Heat Reflective Glass, Insulated Glass, Low-E Glass |
| Vacuum Glass Structure | 5TL+0.2V+5T |
| U-Value | 0.51w.(m².k) |
| Thickness | 10mm |
| Shape | flat |
| Degree of Vacuum | 0.01pa |
| Sound Isolation (dB) | 37 |
| Type | Features | Application |
|---|---|---|
| Architecture | Thin, lightweight, safe, thermal and sound insulation | Doors, windows, curtain walls, and skylights for commercial and residential buildings, public facilities, green buildings as well as landmark structures. |
| Home Appliances | Energy savings, weight, thickness, safety, and condensation free | Ideal for freezers, wine cabinets, and display cases. |
| Building Integrated PV | Thermal insulation and sloped installation. | Solar photovoltaic buildings |
| Agriculture | Thermal insulation and optical transparency | Modern greenhouse farming |
| Transportation | Thermal insulation, soundproofing and condensation free, optical transparency performance | Suitable as flat window materials for automobiles, high-speed rail, aircraft, and vessels. |
